Silicon Carbide UHMWPE Hybrid Protection Plate NIJ III Plus 10x12 Inch SiC PE Composite Multi-Hit Armor Insert
Productdetails:
| Plaats van herkomst: | Hunan, China |
| Merknaam: | High Broad |
| Certificering: | NIJ 0101.06 Level III+, ISO 9001:2015 |
| Modelnummer: | HB-SIC-HYB-3P-1012 |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Betalen & Verzenden Algemene voorwaarden:
| Min. bestelaantal: | 10 stuks |
|---|---|
| Prijs: | USD 20-75 / Piece |
| Verpakking Details: | Individuele EPE-schuimverpakking met golfkartonnen doos, multiplexpallet van exportkwaliteit |
| Levertijd: | 5-7 werkdagen voor monsters, 15-25 dagen voor bulkbestellingen |
| Betalingscondities: | T/T, L/C, Western Union, PayPal |
| Levering vermogen: | 5000 stuks per maand |
|
Gedetailleerde informatie |
|||
| Materiaal: | Siliciumcarbide (SiC) + UHMWPE-composiet | NIJ-beschermingsniveau: | Niveau III+ (M80 NATO + M855 groene punt) |
|---|---|---|---|
| Afmetingen: | 10 x 12 inch (250 x 300 mm) | Dikte: | 10,5 mm (totaal composiet) |
| Gebiedsdichtheid: | 24,8 kg/m² | Gewicht: | 2,45 kg (enkele plaat) |
| Hardheid (slagvlak): | 2600 HV (Knoop) | PE-rugdikte: | 6,5 mm |
| Keramische laagdikte: | 4,0 mm | Multi-hit-mogelijkheid: | 6 ronden M80 + 3 ronden M855 |
| Krommetype: | Multi-Curve SAPI-snede | Houdbaarheid: | 10 jaar |
| Bedrijfstemperatuur: | -40°C tot +70°C | ||
| Markeren: | Silicon Carbide UHMWPE armor plate,NIJ III Plus bulletproof plate,10x12 inch SiC PE composite |
||
Productomschrijving
Silicon Carbide + UHMWPE Hybrid Protection Plate — The Ultimate Cost-Performance Formula
Why Hybrid Design Beats Pure Ceramic or Pure PE Every Time
| Armor Type | Weight (10x12) | NIJ Rating | M855 Stopped | Cost Index |
|---|---|---|---|---|
| SiC + UHMWPE Hybrid | 2.45 kg | III+ Special Threat | YES | 100% (baseline) |
| Alumina + PE Hybrid | 3.1 kg | III+ Special Threat | YES | 85% |
| Pure PE (UHMWPE Only) | 1.6 kg | III (M80 only) | NO | 110% |
| B₄C + PE Hybrid | 2.1 kg | III+ Special Threat | YES | 165% |
The HB-SIC-HYB-3P-1012 hybrid plate represents our optimized cost-performance design. By combining a 4.0mm SiC ceramic strike face with a 6.5mm UHMWPE composite backing, we achieve NIJ III+ special threat protection at a weight and price that neither pure ceramic nor pure PE can match.
- Alumina hybrid plates need thicker ceramic layers (6-7mm) to defeat M855, adding weight — our SiC hybrid is 21% lighter.
- Pure UHMWPE plates cannot stop M855 (SS109) penetrator rounds due to the steel tip piercing through the PE fibers — our SiC face shatters the penetrator on contact.
- Boron Carbide hybrids achieve similar performance but at a 65% cost premium — our SiC design gives you the same defeat capability at a fraction of the price.
Key Features
- NIJ III+ Special Threat Rated: Stops 7.62*51mm M80 NATO AND 5.56*45mm M855 (SS109) Green Tip penetrator rounds
- 4.0mm SiC Strike Face: Optimum thickness calculated for M855 steel penetrator defeat while minimizing weight
- 6.5mm UHMWPE Backing: Industry-standard High-grade PE laminate captures ceramic fragments and minimizes BFD
- Multi-Curve SAPI Cut: Anatomical fit for all-day wear comfort, compatible with standard SAPI/ESAPI plate carriers
- 6+3 Multi-Hit Proven: 6 rounds M80 plus 3 rounds M855 within the NIJ dispersion zone
Ideal For
- Protection units facing both 7.62mm and 5.56mm threats on the modern battlefield
- SWAT teams requiring M855/Green Tip defeat for urban operations
- Border patrol and counter-terrorism units needing multi-threat protection
Get the best cost-performance armor plate on the market. Contact our sales team for pricing, samples, and OEM branding options.
